The Makita HR2630T SDS+ Rotary Hammer Drill is a high-performance, compact, and lightweight tool designed for a wide range of heavy-duty drilling and chiselling tasks. Built to handle demanding construction and renovation jobs, this professional-grade rotary hammer features a 3-mode operation that allows the user to select between rotation only, rotation with hammering, and hammering onlyoffering outstanding flexibility across concrete, masonry, metal, wood, and more.

With a powerful motor and variable speed control via trigger, this rotary hammer ensures precision and comfort during operation. Its one-touch sliding SDS+ chuck allows for quick bit changes without the need for tools, while the torque limiter enhances user safety by disengaging the motor in case the bit jams. The ergonomically designed soft grip handle and balanced weight distribution help reduce fatigue during extended use.

The HR2630T comes complete with a side handle, depth stop, and a durable carry case, making it ready for immediate use on any jobsite.

Key Specifications:

Feature Details Model Makita HR2630T Bit Type SDS-Plus Drilling Capacity Concrete 26 mm Drilling Capacity Steel 13 mm Drilling Capacity Wood 32 mm Modes of Operation 3 (Rotation only, Rotation + Hammer, Hammer only) Chuck Type One-touch sliding SDS+ Speed Control Variable by trigger Max No Load Speed 01,200 RPM Max Impact Rate 04,600 BPM Impact Energy Approx. 2.4 Joules Bit Angle Settings 40 positions Safety Features Torque limiter Handle Ergonomic soft grip Weight (Tool Only) Approx. 2.8 kg Power Supply Corded Electric (240V UK Standard) Insulation Double Insulated

Features & Benefits:

• 3-Mode Functionality
  Switch between drilling, hammer drilling, and chiselling modes for versatility on the jobsite.
• Modified Mode Selector Lever
  Enables smooth transitions between modes without rotating the chuck, reducing wear and improving durability.
• One-Touch SDS+ Chuck
  Allows for quick and tool-free bit changesideal for busy professionals.
• Variable Speed Control by Trigger
  Precise control of drilling speed allows for cleaner results and better accuracy in delicate materials.
• Forward & Reverse Rotation
  Suitable for tightening and loosening fasteners as well as removing bits from material jams.
• Torque Limiter for Safety
  Prevents sudden gear kickback by disengaging the drive if the bit hits reinforcement or jams.
• 40 Angle Settings
  Bit angle can be set in 40 different positions, providing maximum control during chiselling or angled work.
• Ergonomic Soft Grip
  Reduces vibration and hand fatigue, even during long periods of use.
• Compact & Lightweight Design
  Offers excellent handling and balance, perfect for working at height or in tight spaces.
• Depth Stop & Side Handle Included
  Allows for consistent drilling depth and improved stability during heavy drilling operations.
• Robust Carry Case
  Durable case with molded interior for safe storage and transport of the tool and accessories.

Typical Applications:

• Drilling into concrete, brick, and stone
• Chiselling off tile, render, or mortar
• Fixing anchor bolts or rebar
• Through-hole drilling for cables, pipework, or air conditioning
• Wood and metal drilling using appropriate bits

Whats in the Box:

• 1 Makita HR2630T SDS+ Rotary Hammer Drill
• 1 Side Handle (Adjustable)
• 1 Depth Stop Rod
• 1 Durable Makita Carry Case
• Instruction Manual

Frequently Asked Questions (FAQ):

Q: Can this drill be used for chiselling tiles off walls?
A: Yes. Set the tool to Hammer Only mode and use an SDS+ chisel bit for tile removal and other chiselling tasks.

Q: Is this tool suitable for drilling into reinforced concrete?
A: Yes. It is designed for concrete and masonry. The torque limiter helps protect the motor if the bit hits rebar.

Q: Does it support standard drill bits?
A: It supports SDS+ bits. Youll need an SDS+ chuck adapter to use standard smooth-shank bits.

Q: Is this a corded or cordless tool?
A: This is a corded 240V tool, delivering consistent power for heavy-duty applications.

Q: Can I use this for wood and metal drilling?
A: Yes, using the Rotation Only mode and appropriate SDS+ bits or a compatible chuck adapter.

Warranty Information:

The Makita HR2630T is covered by:

• 3-Year Manufacturer Warranty (Tool only)
  Requires online registration within 30 days of purchase
• 1-Year Standard Warranty without registration
• Covers defects in materials and workmanship under normal professional use
• Wear and tear parts (e.g., carbon brushes) not included under warranty

To register and learn more, visit Makita UK Warranty Registration
