Mitutoyo Digital Point Micrometer, 0-25mm – 142-201

Features:

• IP65 water/dust protection (Series 342)
• Pointed spindle and anvil for measuring the web thickness of drills, small grooves, keyways, and other hard-to-reach dimensions
• 15 degree and 30 degree measuring points are available
• Non-slip grip finish (digital models)
• The measuring points have approximately 0.3mm / .012 radius
• With Ratchet Stop for constant force
• With SPC output (Series 342)
• With digit counter (Series 142)
• With a standard bar except 0 – 1″ and 0 – 25mm model
• Supplied in fitted plastic case

Technical Data:

• Accuracy: Refer to the list of specifications.

• Resolution*: .00005″/0.001mm or 0.001mm

• Graduation**: .001 or 0.01mm

• Display*: LCD

• Battery*: SR44 (1 pc.), 938882

• Battery life*: Approx. 2.4 years under normal use

• Dust/Water protection level*: IP65

• Function of Digital Model

• Origin-set, Zero / ABS, Data hold, inch/mm conversion (on inch/metric models only)

• Function lock

• Alarm: Low voltage, Counting value composition error

*Digital models **Analog models
