Multiquick Toolpost, Size C – 71-290-1
Quick Change Tool Post
110mm Tool Post Height, Series C
The majority of quick change tool posts can hold two dovetail shaped toolholders at the same. The clamping mechanism is either a piston that pushes out from the dovetail or a wedge that actuates from the side of the dovetail.
| Type |
Quick Change Tool Post |
| Series |
C |
| Through Coolant |
No |
| Base Width (mm) |
200.00 |
| Tool Post Height (mm) |
110.00 |
| Bolt Hole Diameter (mm) |
40.00 |
| Centerline to Body (mm) |
90.00 |
0.0001″ Accuracy
- Swiss precision and perfection; internationally acclaimed by the leaders in industry
- All parts, toolposts and holders are manufactured from high quality chrome steel, thru hardened
- The splines of the toolpost and holders are precision ground for 0.0001″ repeat accuracy
- Cam-lock handle rigidly locks and quickly releases toolholder
- 40 different angles (every 9) are conveniently selected from position dial with marker
- No limitations as to the number and types of tools to be used
- Correct height of cutting edge is easily and accurately adjusted by a special set-screw built into each holder
- Tools can be re-ground without removal from toolholder setting remains unaltered
- Holders are interchangeable with most other brand 40 position toolposts
Click to Download Multiquick Full Parts Guide PDF
See all parts for the Multiquick: 40 Position Quick Change Tool Holder for all Lathes
