SPI Outside Micrometer, 100-125mm – 14-244-8

• Carbide measuring faces
• Painted frame with satin chrome barrel and thimble
• Standards included above 0-1″ / 0-25 mm range
• Spindle Dia: 0.250″
• Graduation: 0.0001″ / 0.01 mm
• Ratchet thimble
• Spindle lock
• Certificate of calibration traceable to NIST
• Furnished in fitted case

Specifications:

100 to 125 mm Range, 0.01 mm Graduation, Mechanical Outside Micrometer Type Outside Micrometer Minimum Measuring Range (mm) 100.00 mm Maximum Measuring Range (mm) 125.00 mm Style Ratchet Stop Graduation (mm) .01 mm Thimble Ratchet Stop Finish/Coating Satin Chrome / Baked Enamel Accuracy (mm) 0.006 mm Face Material Carbide Number of Standards 1 Manufacturers Catalog Number 14-244-8 Includes Certificate of Calibration Traceable to NIST SPI Part Number 14-244-8

See all SPI Outside Micrometers (Metric)
